v2.0
LDK 8000 User’s Guide | Menu structure and contents 6-11
6.2.3 Video menu contents
MENU VALUES DESCRIPTION LEVEL FILE
Colour Filter 0..99 (50) This electronic colour filter varies the colour
balance to obtain warmer or colder effects for
the auto-white memory positions. It resets to
50 when the next automatic white balance
process is carried out. 2 Sc.
Contour Level 0..99 (30) Set contour enhancement level. 2 Sc.
Contour
Level 0..99 (50) Set contour enhancement level. 3 Sc.
Source select Y, R, G, R+G Select source to be used for contour
generation: Y before knee, R, G, or average of
R+G. 3 Sc.
vert cont 0..99 (50) Adjust the level of vertical component in the
contour signal. 3 Sc.
coarse/fine 0..99 (5) Adjust the coarseness of the contours (0 is very
fine). 3 Sc.
Soft Contour
Soft Contour Off, On Set to On to reduce the amount of contour
added for large transitions. 2 Sc.
Level 0..99 (70) Adjust the upper limit level of contour
enhancement for soft contours. 2 Sc.
Knee Contour Off, 1, 2, 3, 4 Select a level of contour enhancement for the
compressed signal above the knee (4 is high
level of enhancement). 3 Sc.
Skin Use skin contour to change the contour level
within a selected colour range.
Skin Off, 1, 2, 1+2 Turns on skin contour and selects the memory
position. 2 Sc.
Auto Off, On Select to take a sample of the skin colour. 2 -
View Off, On Set to on to indicate the selected area. 2 -
Skin Level 0..99 (15) Decrease the skin contour level below 50 to
soften the selected area. Increase the value
above 50 to add extra contour. 2 Sc.
width1 Red 0..99 (50) Manual correction of skin gate (red saturation)
for memory position 1.
The higher the number, the broader the range. 3 Sc.
width1 Blue 0..99 (50) Manual correction of skin gate (blue saturation)
for memory position 1. 3 Sc.
color1 Red 0..99 (50) Manual correction of skin gate (red color) for
memory position 1. 3 Sc.
color1 Blue 0..99 (50) Manual correction of skin gate (blue color) for
memory position 1. 3 Sc.
width2 Red 0..99 (50) Manual correction of skin gate (red saturation)
for memory position 2. 3 Sc.
width2 Blue 0..99 (50) Manual correction of skin gate (blue saturation)
for memory position 2. 3 Sc.
