v2.0
LDK 8000 User’s Guide | Menu structure and contents 6-12
color2 Red 0..99 (50) Manual correction of skin gate (red color) for
memory position 2. 3 Sc.
color2 Blue 0..99 (50) Manual correction of skin gate (blue color) for
memory position 2. 3 Sc.
Black
Blackstretch 0..99 (99) Set black stretch level (50 is no stretch, values
below 50 are black press) 3 Sc.
Master 0..99 (50) Black level adjustment – RGB 2 Sc.
3
Red 0..99 (50) Black level adjustment – R 3 Sc.
Green 0..99 (50) Black level adjustment – G 3 Sc.
Blue 0..99 (50) Black level adjustment – B 3 Sc.
Master 0..99 (50) Black level adjustment – RGB 3 Sc.
Gain
Red 0..99 (50) Manual red gain control 2 Sc.
Green 0..99 (50) Manual green gain control 2 Sc.
Blue 0..99 (50) Manual blue gain control 2 Sc.
Range 3dB, 6dB Gain control step size 2 Op.
Knee Off, Auto, Var Knee Off, Auto, or variable (manual) 2 Sc.
Knee -
Knee Off, Auto, Var Knee Off, Auto, or variable (manual) 3 Sc.
Knee Type Y, NAM Signal used for knee. (NAM: luminance of
highest RGB component) 3 Sc.
Slope M 0..99 (60) Adjusts the knee slope angle in manual mode 3 Sc.
Point M 0..99 (50) Adjusts the knee slope point in manual mode 3 Sc.
Gamma Nom, Low, Pre Select Normal, Low (linearised on each selected
curve) or Pre (manual curve). 2 Sc.
Gamma
Gamma Nom, Low, Pre Select Normal, Low (linearised on each selected
curve) or Pre (manual curve). 3 Sc.
Master 0..99 (76) Adjust the RGB gamma curves manually. 3 Sc.
Red 0..99 (76) Adjust the red gamma curve manually. 3 Sc.
Green 0..99 (76) Adjust the green gamma curve manually. 3 Sc.
Blue 0..99 (76) Adjust the blue gamma curve manually. 3 Sc.
Matrix EBU, Skin, B/W, RAI, BBC,
1:1, CoolFL EBU: True colour matrix.
SKIN: Optimised for skin tone reproduction.
B/W: Monochrome picture
RAI: SONY cameras impression.
BBC: BBC optimisation.
1:1: Matrix is off.
COOLFL: Optimised for mixed fluorescent and
incandescent lighting. 3 Sc.
Saturation 0..99 (50) Adjust saturation 0 Sc.
MENU VALUES DESCRIPTION LEVEL FILE
