2. When installing, avoid pressing the standby switch and accidentally turning the system on or
off.
Disk module removal
Before doing this task, do the following:
• Make sure you have identified the proper disk module. In some cases you must also perform
operations with Storage Utility.
• Remove the front bezel assembly.
To remove a disk module, proceed as illustrated.
Loosen
thumbscrews 1
Slide out 2
02 February 2012 K2 Summit 3G Production Client Service Manual 99
Removing and replacing FRUs
