8990ARC Instruction Manual 47
Specifications
Active lines blanked before process-
ing by scaling circuit
525
Data Lines control setting (Number of blanked lines)
None No active or half-lines blanked
1 Line 21 blanked (top)
Line 284 blanked (top)
Line 263 blanked (bottom)
Line 525 blanked (bottom)
2 Line 21 blanked (top)
Line 284 blanked (top)
Line 22 blanked (top)
Line 285 blanked (top)
Line 262 blanked (bottom)
Line 524 blanked (bottom)
Line 263 blanked (bottom)
Line 525 blanked (bottom)
3 Line 21 blanked (top)
Line 284 blanked (top)
Line 22 blanked (top)
Line 285 blanked (top)
Line 23 blanked (top
Line 286 blanked (top)
Line 261 blanked (bottom)
Line 523 blanked (bottom)
Line 262 blanked (bottom)
Line 524 blanked (bottom)
Line 263 blanked (bottom)
Line 525 blanked (bottom)
Table 10. 8990ARC Specifications
Parameter Value
