22 8990ARC Instruction Manual
Configuration
010 16:9
4x3
Invalid Default to next highest priority control
4:3 Mode 1: Bypass
16:9 Mode 2: Letterbox
16x9
Invalid Default to next highest priority control
4:3 Mode 3: Full Width
16:9 Mode 1: Bypass
011 14:9
4x3
Invalid Default to next highest priority control
4:3 Mode 1: Bypass
16:9 Mode 4: 14:9 Horizontal Crop
16x9
Invalid Default to next highest priority control
4:3 Mode 4: 14:9 Top and Bottom Crop
16:9 Mode 1: Bypass
100 Reserved N/A Invalid Default to next highest priority control
101
4:3 with shoot and
protect 14:9 center
4x3
Invalid Default to next highest priority control
4:3 Mode 1: Bypass
16:9 Mode 4: 14:9 Horizontal Crop
16x9
Invalid Default to next highest priority control
4:3 Mode 4: 14:9 Top and Bottom Crop
16:9 Mode 1: Bypass
110
16:9 with shoot and
protect 14:9 center
4x3
Invalid Default to next highest priority control
4:3 Mode 1: Bypass
16:9 Mode 4: 14:9 Horizontal Crop
16x9
Invalid Default to next highest priority control
4:3 Mode 4: 14:9 Top and Bottom Crop
16:9 Mode 1: Bypass
111
16:9 with shoot and
protect 4:3 center
4x3
Invalid Default to next highest priority control
4:3 Mode 1: Bypass
16:9 Mode 3: Full Height
16x9
Invalid Default to next highest priority control
4:3 Mode 2: Pillarbox
16:9 Mode 1: Bypass
Table 6. Modified Video Index Coding – ARD
ARD Value
(b5, b4, b3)
Definition
Selected Output
Format
AID Status Resulting Module Mode
