26 8990ARC Instruction Manual
Configuration
Configuration Summary
Table 8 provides a complete summary of the 8990ARC functions and a
comparison of the functionality available with each control type along with
the ranges and default values for each parameter. Refer to the specific
control type for more details on using each control.
Table 8. Summary of 8990ARC Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Rotary Switch
Bank/Setting
Newton
Panel
Output Format
(aspect ratio)
16:9 16:9 or 4:3
Settings/
Output Format pulldown
1:1 OutptFmt
V Process BW
(vertical resizing)
High High or Low
Settings/
V Process BW pulldown
1:6 VProcBW
Conversion Mode
Pillarbox
(16:9)
Bypass
Pillarbox (16:9) or Letterbox (4:3)
Full Width (16:9) or Full Height (4:3)
14:9
Settings/
Conversion Mode
pulldown
1:2 ConvMode
Pan (horizontal) Centered
Left,
Centered,
or Right
Settings/
Pan pulldown
1:3 Pan 1
Tilt (vertical) Centered
Top,
Centered,
or Bottom
Settings/
Tilt pulldown
1:3 Tilt 1
VANC Data Blanked Blanked or Pass
Settings/
VANC Data pulldown
1:7 VANCData
Data Line processing None
None
1 Line
2 Lines
3 Lines
Settings/
Data Lines pulldown
1:5 DatLines
Video Index Control Disable
Disable,
Standard,
Modified,
or Custom
Settings/
Video Index Control pulldown
1:4
1:8
VidIdCtl
WSS Control Disable
Disable,
Standard,
Modified,
or Custom
Settings/
WSS Control pulldown
1:4
1:8
WSS Ctrl
WSS/Vid Input LSBs
(Custom Conversion
Mode selected in Con-
version Mode pull-
down)
000
000,
001,
010,
011,
100,
101,
110,
111
Settings/
WSS/Vid Input LSBs pulldown
N/A N/A
Resulting 16x9 Mode
(16x9 Output format
selected)
No Change
No Change,
Bypass,
Pillarbox,
Full Width Top,
Full Width Center,
Full Width Bottom,
14:9 Top,
14:9 Center,
14:9 Bottom
Settings/
Resulting 16:9 Mode pulldown
N/A N/A
