8990ARC Instruction Manual 27
Configuration
Newton Pan/Tilt Control
In the Newton Control System, only the Pan or the Tilt setting can appear at
one time in the Newton Configurator module view. If both controls are
needed on a Newton Control Panel configuration, do the following:
1. Set the Settings web page so that the Pan control is visible
(16:9 – Pillarbox and 14:9 or 4:3 – Full Height).
2. Using NetConfig, click on the Newton Configurator icon (shown at left)
at the top of the screen to open the application.
Resulting 4x3 Mode
(4x3 Output format
selected)
No Change
No Change,
Bypass,
Letterbox Top,
Letterbox Center,
Letterbox Bottom,
Full Height,
14:9 Top,
14:9 Center,
14:9 Bottom
Settings/
Resulting 4x3 Mode pulldown
N/A N/A
WSS Line Line 23
Line 13-27
Default can be set with local control
Settings/
WSS Line pulldown
1:F
1:9 2 WSSLine
GPI Control Disable Enable or Disable
Settings/
GPI Control pulldown
1:9 1 GPICtrl
Recall or Save User
settings
– Recalls or saves module setup
Save/Recall Settings/
Recall or Save User
Settings button
1:E N/A
Recall or Save GPI 1 – Save or recall settings for GPI 1
Save/Recall Settings/
Recall or Save GPI 1
Settings button
1:A N/A
Recall or Save GPI 2 – Save or recall settings for GPI 2
Save/Recall Settings/
Recall or Save GPI 2
Settings button
1:B N/A
Recall or Save GPI 3 – Save or recall settings for GPI 3
Save/Recall Settings/
Recall or Save GPI 3
Settings button
1:C N/A
Recall or Save GPI 4 – Save or recall settings for GPI 4
Save/Recall Settings/
Recall or Save GPI 4
Settings button
1:D N/A
Recall Factory Defaults – See Default column
Save/Recall Settings/
Recall Defaults button
1:F N/A
1 Refer to Newton Pan/Tilt Control below for special instructions on enabling these controls.
2 This is a dual control: Paddle switch in the up position disables GPI control and sets WSS to default of Line 23.
Table 8. Summary of 8990ARC Configuration Functions
Function
Type
Default
Range/Choices
Resolution
Web Page/
Function Name
Rotary Switch
Bank/Setting
Newton
Panel
