8981FS Instruction Manual 3
Installation
Installation
Installation of the 8981FS module consists of:
1. Placing the module in the proper frame slot, and
2. Cabling and terminating signal ports.
The 8981FS module can be plugged in and removed from an 8900 Series
frame with power on. When power is applied to the module, LED indica-
tors reflect the initialization process (see
Power Up on page 7 ).
Frame Capacity
The 8981FS module can be installed in all 8900 Series frames but with
varying maximum quantities determined by frame cooling capacity.
Table 1 provides the power capacity, cooling capacity, and maximum
module count for each frame type.
Note Module capacity figures assume no other modules are in the frame.
Table 1. Power, Cooling, and Module Capacity of 8900 Frames
Capacity Calculated
8900T2
Frame
8900T2-F
Frame
8900TX
Frame
8900TF
Frame
8900TFN
Frame
Power (W) 60 60 100 100 100
Recommended Module Cooling (W) 30 60 30 90 90
8981FS Modules 6 10 6 10 10
