16 8981FS Instruction Manual
8981FS Digital Frame Synchronizer Module
Bank 2 - 2nd Func On
0 Inactive position
1 Increase Decrease Adjust Y channel offset ±31 least significant bits.
2 Increase Decrease Adjust B-Y channel offset ±31 least significant bits.
3 Increase Decrease Adjust R-Y channel offset ±31 least significant bits.
4 Increase Decrease Adjust Y channel gain ±49%.
5 Increase Decrease Adjust B-Y channel gain ±49%.
6 Increase Decrease Adjust R-Y channel gain ±49%.
7 thru 9 Not used.
A Not used.
B Disable
1
Enable Enable/disable Freeze GPI. Disable to guard against errant GPI input.
C 20 lines 1 21 lines Select 525 format vertical data blanking width (see Bank 1, position 4).
D Store Save current settings to EE prom.
E Restore defaults Restore User Recall factory defaults or stored user settings.
F Inactive position
1 Restored default setting.
Table 3. 8981FS Configuration Functions - (continued)
Function
Switch
Toggle
Switch Up
Toggle
Switch Down
Function Description
