8981FS Instruction Manual 27
Specifications
Specifications
Table 4. 8981FS Specifications
Parameter Value
Inputs
Number of inputs 1 Serial Digital Input (SDI)
Input signal formats 8 or 10 bits Serial Digital Component video per SMPTE 259M-C or
EBU tech 3267
Impedance 75 Ω, terminating
Return loss >15 dB, 5 to 270 MHz
Connector 75 Ω BNC
Maximum Input Cable Length 300 m (984 ft) of 8281 or equivalent cable
Outputs
Number of outputs 4
Signal Type Serial digital video conforming to SMPTE259M-C or EBU 3267
Output Impedance 75 Ω
Connector type 75 Ω BNC on 8900 frame
Output Return Loss > 15 dB, 5 to 270 MHz
Reference Input
Signal Type Analog color black, 525 or 625 lines, per SMPTE 170M or CCIR 624
Signal Level Sync: 140 mV to 560 mV p-p
Input Impedance High impedance
Connector type 75 Ω BNC on 8900 frame, loop through
Return Loss > 40 dB to 5 MHz
Delay Track Output
Number of outputs 2
Connector type BNC
Output impedance High impedance-do not terminate
Format Compatible with Grass Valley automatic tracking audio delay products
Signal Processing
Signal path 10 bits
Environmental
Frame temperature range 0 to 45 degrees C
Operating Humidity Range 0 to 90% non-condensing
Non-operating Temperature -10 to 70 degrees C
Mechanical
Frame type 8900 Series
Power Requirements
Supply voltage +12V, -12V
Power Consumption 5.0 Watts
