54 8947RDA-D/-FR — Instruction Manual
Specifications
Rear module retainer maximum
screw torque 4-5 inch-lb./0.45-0.6Nm
Frame temperature range
Refer to GeckoFlex Frames 8900FX/FF/FFN Signal Processing Systems
Instruction Manual at
www.grassvalley.com/docs/modular
Operating humidity range
Non-operating temperature
UL and EU compliance When installed in a GeckoFlex frame
Table 8. Receiver/Transceiver Fiber Optic SFP Device Specifications
Model Number SFP-13103G-M1DRX SFP-13103G-M1TRX
Low wavelength 1260nm 1260nm
High wavelength 1620nm 1620nm
Receiver channels 2 1
Connector type LC
Fiber support Single mode
Data rate 50Mb/s to 3Gb/s
Maximum distance @ 3Gb/s 10km
Minimum distance 30km
Table 9. Transmitter/Transceiver Fiber Optic SFP Device Specifications
Model Number SFP-13103G-M2DTX SFP-13103G-M1TRX
Wavelength 1 1310 nm 1310 nm
Wavelength 2 1310 nm N/A
Transmit channels 2 1
Connector type LC
Fiber support Single-mode
Data rate 143 Mb/s to 2.97 Gb/s
Power output -5 to 0 dBm (-2dBm typical)
Maximum distance 10 km
1
1
The 1310 nm Dual Transmitter (SFP-13103G-M1DTX) and Transceiver (SFP-13103G-M1TRX) require no attenu-
ation between fiber transmitter and receiver connections at any length.
Maximum distance 20 km
Table 7. 8947RDA Specifications
Parameter Value
