Remote Configuration
8947RDA-D Status Web Page
Use
this
link
The Status web page (
) shows the signal status of the
input signal(s) and communication with the frame bus. Color coding of the
display indicates the signal status. Refer to
Web Browser Interface on page 27
for an explanation of the color coding.
•
Under the
Status
title are given the model, the description and the frame
location. The graphic shows the input and output signals and their
status based on color. If the status of either input or output changes, it
will be reflected in the color status of the arrow (linked to the
Input
Reporting
parameter) and the status LED on the module web page.
•
Information about the module, such as Part Number, Serial Number,
Hardware Revision, Firmware Revision 1 (CPLD), Firmware Revision
2 (FPGA), Software Version, and Asset Tag number are given at the
bottom of the Status Web Page.
•
On the Status web page, any warnings or module errors will be dis-
played in the double bars area below the graphic.
Note
The color of the LED present on the top left of each web page is managed by
the 8900NET accordingly to the alarms status.
