[SwitchC] interface tunnel 3 mode vxlan
[SwitchC-Tunnel3] source 3.3.3.3
[SwitchC-Tunnel3] destination 2.2.2.2
[SwitchC-Tunnel3] quit
# Assign Tunnel 1 and Tunnel 3 to VXLAN 10.
[SwitchC] vsi vpna
[SwitchC-vsi-vpna] vxlan 10
[SwitchC-vsi-vpna-vxlan10] tunnel 1
[SwitchC-vsi-vpna-vxlan10] tunnel 3
[SwitchC-vsi-vpna-vxlan10] quit
[SwitchC-vsi-vpna] quit
# Create VLAN 2, and assign FortyGigE 1/0/1 to VLAN 2.
[SwitchC] vlan 2
[SwitchC–vlan2] port fortygige 1/0/1
[SwitchC–vlan2] quit
# On FortyGigE 1/0/1, create Ethernet service instance 1000 to match frames from VLAN 2.
[SwitchC] interface fortygige 1/0/1
[SwitchC-FortyGigE1/0/1] service-instance 1000
[SwitchC-FortyGigE1/0/1-srv1000] encapsulation s-vid 2
# Map Ethernet service instance 1000 to the VSI vpna.
[SwitchC-FortyGigE1/0/1-srv1000] xconnect vsi vpna
[SwitchC-FortyGigE1/0/1-srv1000] quit
[SwitchC-FortyGigE1/0/1] quit
Verifying the configuration
1.
Verify the VXLAN IP gateway settings on Switch B:
# Verify that the VXLAN tunnel interfaces are up on Switch B.
[SwitchB] display interface tunnel 2
Tunnel2
Current state: UP
Line protocol state: UP
Description: Tunnel1 Interface
Bandwidth: 64 kbps
Maximum transmission unit: 64000
Internet protocol processing: Disabled
Last clearing of counters: Never
Tunnel source 2.2.2.2, destination 1.1.1.1
Tunnel protocol/transport UDP_VXLAN/IP
# Verify that VSI-interface 1 is up.
[SwitchB] display interface vsi-interface 1
Vsi-interface1
Current state: UP
Line protocol state: UP
Description: Vsi-interface100 Interface
Bandwidth: 1000000kbps
Maximum transmission unit: 1500
Internet Address is 10.1.1.1/24 Primary
