# Create a VXLAN tunnel to Switch A. The tunnel interface name is Tunnel 1.

[SwitchC] interface tunnel 1 mode vxlan

[SwitchC-Tunnel1] source 3.3.3.3

[SwitchC-Tunnel1] destination 1.1.1.1

[SwitchC-Tunnel1] quit

# Create a VXLAN tunnel to Switch B. The tunnel interface name is Tunnel 3.

[SwitchC] interface tunnel 3 mode vxlan

[SwitchC-Tunnel3] source 3.3.3.3

[SwitchC-Tunnel3] destination 2.2.2.2

[SwitchC-Tunnel3] quit

# Assign Tunnel 1 and Tunnel 3 to VXLAN 10.

[SwitchC] vsi vpna

[SwitchC-vsi-vpna] vxlan 10

[SwitchC-vsi-vpna-vxlan10] tunnel 1

[SwitchC-vsi-vpna-vxlan10] tunnel 3

[SwitchC-vsi-vpna-vxlan10] quit

[SwitchC-vsi-vpna] quit

# Create VLAN 2, and assign FortyGigE 1/0/1 to VLAN 2.

[SwitchC] vlan 2

[SwitchC–vlan2] port fortygige 1/0/1

[SwitchC–vlan2] quit

# On FortyGigE 1/0/1, create Ethernet service instance 1000 to match frames from VLAN 2.

[SwitchC] interface fortygige 1/0/1

[SwitchC-FortyGigE1/0/1] service-instance 1000

[SwitchC-FortyGigE1/0/1-srv1000] encapsulation s-vid 2

# Map Ethernet service instance 1000 to the VSI vpna.

[SwitchC-FortyGigE1/0/1-srv1000] xconnect vsi vpna

[SwitchC-FortyGigE1/0/1-srv1000] quit

[SwitchC-FortyGigE1/0/1] quit

Verifying the configuration

Verify the VXLAN settings on the VTEPs. This example uses Switch A.
# Verify that the VXLAN tunnel interfaces on the VTEP are up.

[SwitchA] display interface tunnel 1

Tunnel1

Current state: UP

Line protocol state: UP

Description: Tunnel1 Interface

Bandwidth: 64 kbps

Maximum transmission unit: 64000

Internet protocol processing: Disabled

Output queue - Urgent queuing: Size/Length/Discards 0/100/0

Output queue - Protocol queuing: Size/Length/Discards 0/500/0

Output queue - FIFO queuing: Size/Length/Discards 0/75/0

Last clearing of counters: Never

Tunnel source 1.1.1.1, destination 2.2.2.2

Tunnel protocol/transport UDP_VXLAN/IP
