55
[SwitchC-FortyGigE1/0/1-srv1000] quit
# On FortyGigE 1/0/1, create Ethernet service instance 2000 to match VLAN 5. Map Ethernet
service instance 2000 to the VSI vpnb.
[SwitchC-FortyGigE1/0/1] service-instance 2000
[SwitchC-FortyGigE1/0/1-srv2000] encapsulation s-vid 5
[SwitchC-FortyGigE1/0/1-srv2000] xconnect vsi vpnb
[SwitchC-FortyGigE1/0/1-srv2000] quit
[SwitchC-FortyGigE1/0/1] quit
# Start the VXLAN IS-IS process. Enable VXLAN autonegotiation and MAC advertisement.
[SwitchC] vxlan-isis
[SwitchC-vxlan-isis] negotiate-vni enable
[SwitchC-vxlan-isis] mac-synchronization enable
[SwitchC-vxlan-isis] quit
Verifying the configuration
1. Verify the configuration on the VTEPs. This example uses Switch A.
# Verify that all VXLAN tunnel interfaces are up.
[SwitchA] display interface tunnel
Tunnel 1
Current state: UP
Line protocol state: UP
Description: Tunnel1 Interface
Bandwidth: 64 kbps
Maximum transmission unit: 64000
Internet protocol processing: Disabled
Last clearing of counters: Never
Tunnel source 1.1.1.1, destination 2.2.2.2
Tunnel protocol/transport UDP_VXLAN/IP
Tunnel 2
Current state: UP
Line protocol state: UP
Description: Tunnel2 Interface
Bandwidth: 64 kbps
Maximum transmission unit: 64000
Internet protocol processing: Disabled
Last clearing of counters: Never
Tunnel source 1.1.1.1, destination 3.3.3.3
Tunnel protocol/transport UDP_VXLAN/IP
# Verify VSI information. Make sure the VXLAN ID and Ethernet service instance for each VSI are
correct, and VXLAN tunnels have been assigned to the correct VXLANs.
[SwitchA] display l2vpn vsi verbose
VSI Name: vpna
VSI Index : 0
VSI State : Up
MTU : 1500
