Installation Guide
Step 5: Connect the Cable(s)
1.
Insert the Ethernet cable through the cable gland body and connect it to the Ethernet port of
the camera.
2.
Insert the sealing insert with claw into the cable gland body and then attach the clamping nut
to complete the cable solution.
NOTE:
Make sure the clamping nut is tightly attached to the cable gland body.
