Step 2: Attach the Tilted Mount
Attach two (2) screws (included in the pole mount package) to secure the tilted mount to the pole
mount.
Step 3: Open the Camera Cover
1. Remove the cap covering the bottom hole of the camera, and attach the cap to the side hole
to close it. The network cable will pass through the bottom hole.
2. Loosen the three (3) screws using the supplied hex wrench.
