Installation Guide
Step 6: Install the Camera to the Tilted Mount
1.
If necessary, insert a memory card into the card slot of the camera.
2.
Align the camera to the tilted mount as the cable is pushed through the cable hole on the
tilted mount and pole mount.
3.
Attach the camera to the tilted mount using the three (3) screws supplied in the Tilted Mount
package.
NOTE:
Make sure the tilted mount screws have rubber rings. If the screws you received do
not have rubber rings, please contact your local sales agents or our
for support.
Rubber Ring
