Installation Guide
7
2. Disassemble the cable gland as shown below:
3. Insert the clamping nut into the Ethernet cable of the camera side.
4. Insert the sealing insert with claw.
5. Attach the cable gland body to the hole of the camera.
Body
(with Washer)
Sealing Insert
with Claw
Clamping
Nut
