Connections, Ac b d – Teac P-02 User Manual
Page 8
8
Digital audio input
terminals
Amp or other device with a D/A
converter/digital input
Either i.LINK port
can be used.
Use the one that
matches the cable.
D-02
Super Audio CD/CD transport (P-02)
Wall socket
Supplied power cor
d
A
A
A
A
C
B
D
XLR digital coaxial cable
XLR digital coaxial cable
i.LINK cable
RCA digital coaxial cable
BNC coaxial cable
Connections
After all connections are complete, connect the power cord’s plug to the AC wall socket.
< Read the instructions of each device that you intend to use with this unit.
< Be sure to connect each plug securely. To avoid hum and noise, do not bundle the connection cords.
XLR pins
1. COMMON
2. HOT (+)
3. COLD (−)
