TASCAM DR-07MKII
27
Left side panel
i
/LINE OUT jack
Use this to connect with headphones or the
line input jack of an amp or other equipment.
o
HOLD switch
Shift to the left end (in the direction of the
arrow) to engage the hold function.
All buttons are inoperative when hold is ON.
Right side panel
p USB port
Use the included USB cable to connect with a
computer USB port.
Power can be supplied through the USB
cable provided with the unit or an AC
adaptor (sold separately: TASCAM PS-P515U).
a
microSD card slot
Insert a microSD card into this slot.
2–Names and Functions of Parts
