IEC Lead Test
33
For IEC Leads
Plug the lead into the tester outlet socket and plug the IEC end into
the tester’s IEC socket.
For Extension Leads
Plug the lead into the tester outlet socket and use a short IEC lead to
connect from the tester’s IEC socket to the extension lead outlet
socket.
Test Description
The IEC test performs in sequence an earth continuity, insulation and
polarity check on the Live and Neutral conductors and confirms that
there are no breaks or cross wiring in these conductors.
User Selectable Settings
Each press of the SELECT button will allow you to switch between
user selectable test limit for Earth Continuity and Insulation. The
currently selected setting for the selected test will be flashing.
Note
To determine which test limit is currently displayed, observe the unit
of measurement symbol. For Earth Continuity
Ω is displayed. For
Insulation M Ω is displayed.
Test Limits
With the secondary display flashing use the cursor keys to step
through the test limits available and stop with the appropriate limit
displayed.
A special limit indicated by a plus sign (+) to the left of the limit, is a
user adjustable limit.
Press SELECT to swap between the Earth Bond and Insulation
pass/fail limits.
