165
k
10.1.4 Lighting conditions (RATIO) for the
flash groups settings on the master
flash unit
The lighting conditions of the flash groups (A,
B, C) can be set proportionally in order to
obtain specific lighting effects. The lighting
conditions for all groups are controlled exclu-
sively via the master flash unit.
• Press the
ቨ button as often as it takes
for the selection menu to appear.
• Press the sensor button on the
touch display.
• Press the sensor buttons on the
touch display and select "RATIO".
• Press the sensor button on the
touch display.
• Press the desired sensor button on the
touch display:
all three groups are the same (RATIO Off).
Ratio of group A to group B.
Ratio of group A to group B plus an
exposure correction (EV) for group C.
The setting is adopted immediately.
RATIO
A+B+C
A : B
A : BIC
PARA
10.1.4.1 Lighting conditions for flash groups
A + B settings on the master flash
unit
• If lighting conditions are to be set for slave
flash group A+B, then press sensor button
on the touch display until the selecti-
on of ratio settings appears.
• Press the or sensor buttons on the
touch display and set the lighting conditi-
ons (e.g. 1: 4) for the slave flash groups.
• Press the sensor button.
The selected setting is adopted.
A : B
B A
1 : 4
RATIO
A : B
1 : 1
A B
RATIO
A : B
1 : 4
A B
REMOTE MASTER
INFO A : B
A : B
1 : 1
E TTL + 1
REMOTE MASTER
INFO A : B
A : B
1 : 4
E TTL + 1
ZOOM
RATIO
CHANNEL
A+B+C
A : B
A : BIC
