148
k
3.3 Switching the flash unit on and off
• Switch on the flash unit with the
ባ button.
The start screen appears.
The flash unit always switches on after-
wards with the mode of operation that was
used last (e.g. manual flash mode M).
The ቨ button flashes red in stand-by
mode. To switch off the flash unit, press
the
ባ button until all displays turn off.
If the flash unit will not be used for an exten-
ded period of time, we recommend that you
switch off the flash unit with the
ባ but-
ton and remove the power source (disposa-
ble/rechargeable batteries).
3.4 The selection menu
• Press the
ቨ button as often as it takes
for the selection menu to appear.
The selection menu is divided into 4 sensor
buttons:
The modes of operation can be set after
pressing the
button.
E TTL, see 7.1
E TTL HSS*, see 7.4
M, see 7.3
M HSS*, see 7.4
MASTER, see 10.1
SLAVE, see 10.2
SERVO, see 10.4
*) only after data exchange with a camera
MODE
The flash parameters can be set after
pressing the
button.
EV (exposure correction),
see 10.1.3, 10.1.4.2
Zoom (reflector setting), see 9.1
F (aperture)
ISO (light sensitivity),
P (partial light output), see 7.3 and 10.1.5
RATIO
2) (lighting conditions), see 10.1.4
CHANNEL 3) (Channel), see 10.2.2
MASTER 3) (Master on-off), see 10.1.1
GROUP 3) (slave group), see 10.2.3.
2) only in MASTER mode
3) only in SLAVE mode
The touch display can be configured after
pressing the
button, or the flash unit
can be reset to the factory setting.
CONTRAST , see 14.1
BRIGHTNESS , see 14.2
ROTATION (rotate the screen display),
see 14.3
RESET, see 15.3
SERVICE
PARA
☞
52AF-1
CAN
