CB-7080 & CB-7080D Counter/Timer User's Guide Application notes
1-10
Counter input applications
The counter mode type is indicated by entering 50 in the command.
Table 1-7. Counter mode settings
Counter 0 Counter 1
$AAB0 to set input mode 0
$AA1H(data) and $AA1L(data)
Non-isolated channel 0 and
threshold value active Non-isolated channel 1 and
threshold value active
$AAB1 to set input mode 1
$AA1H(data) and $AA1L(data)
Isolated channel 0 Isolated channel 1
$AAB2 to set input mode 2
$AA1H(data) and $AA1L(data)
Non-isolated channel 0 and
threshold value active Isolated channel 1
$AAB3 to set input mode 3
$AA1H(data) and $AA1L(data)
Isolated channel 0 Non-isolated channel 1 and
threshold value active
Note:
The threshold value commands $AA1H(data) and $AA1L(data) are effective to non-isolated inputs only.
Configuration Code
Use the configuration codes listed in the following tables to set the baud rate, check the status of, and set the
input type of a module.
Table 1-8. Baud Rate Configuration Code: CC
CC Baud Rate
03 1200 BPS
04 2400 BPS
05 4800 BPS
06 9600 BPS
07 19200 BPS
08 38400 BPS
09 57600 BPS
0A 115200 BPS
Table 1-9. Status Configuration Code: FF, 2-char (for all)
7 6 5 4 3 2 1 0
0 checksum
0=disabled
1=enabled
0 0 0 frequency gate time
0: 0.1 second
1: 1.0 second
0 0
Table 1-10. Input Type Configuration Code: TT
TT Input Range
50 Counter
51 Frequency
