Page 21 HX100/HX150
“M” Indicator
The “ M” indicator shows the channel is in the transceiver’s “Scan Memo-
ry”.
“ ” Battery Indicator
“ ”: Full battery
“ ”: Lower battery
“ ”: Battery is very low
“ (Blinking)”: Prepare to charge the battery
“ U/I/C” Indicator
The “ U/I/C” indicators show the “band” of operation. “U” indicates the USA
band; “ I” indicates the International band; and “C” indicates the Canadian
band.
“ ” Indicators
The “ ” indicator shows the TX output power is “Low” (1 Watt) power.
NOTE
When the “ ” icon is not shown the power is set to 5 Watts (for
HX150) or 2.5 Watts (HX100).
“WX ALT” Indicator
“ WX”: NOAA weather channel is selected.
“ WX ALT”: “Weather Alert” is received.
“TW DW” Indicator
“ TW”: Tri-Watch is activated.
“ DW”: Dual Watch is activated.
Channel Display
The operating channel is shown on the LCD in both the transmission and
reception modes.
