66 | Install and Start Network Discovery
Network Discovery
Note:
If you decide to perform this procedure, you must have purchased an
internal modem according to the specifications in
.
To connect the Peregrine appliance to a telephone line
1
Plug one end of a telephone line cable into the modem connector on the
back of the Peregrine appliance.
2
Plug the other end of the cable into a standard telephone line connector.
Note:
If you do not connect the Peregrine appliance to a telephone line, you will
see a warning on the Appliance Health report (Status > Appliance
Health). To suppress this warning, you need to turn off the “Modem
Warning,” see
Disabling modem warnings on page 90
.
(Optional) Using terminal emulation software
You can use an RS-232 serial cable to connect a terminal or a workstation
running terminal emulation software instead of the keyboard and monitor any
time you need to access the configuration interface—with one exception. You
must use a keyboard and monitor to change the BIOS (see
).
To use a terminal or a workstation running terminal emulation software
1
Use an RS-232 serial cable to connect the terminal or workstation to the
serial connector on the Peregrine appliance.
2
If you are using terminal emulation software, start the program. (For
example, in Windows, Start > Programs > Accessories > Communications
> HyperTerminal).
3
The terminal must meet the following requirements or, if you are using
terminal emulation software, use the following settings.
