2082 power & interlock hookup – Formax FD 2092 User Manual
Page 11
2082 POWER & INTERLOCK HOOKUP
Burster
Sealer
No. NAME
FUNCTION
1
Interlock
Shuts down the burster from the folder
2
Burster Power Cord
Connects power from burster to sealer
3
Folder Power Cord
Connects power from folder to sealer
4
Main Power Cord
Supplies power from wall to machine
5
Bypass plug
Bypasses
6
Interlock
Shuts down the sealer from folder
7
Interlock
Shuts down the folder from sealer
8
Folder Power Switch
Press to supply power to folder
1
2
3
4
5
6
7
8
Folder
9
