74 DR
®
VERSA-PRO
™
Z-MOWER
Parts List - Hydro Tank Assembly
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
01 226401 Tank, Hydro, Metal
02 200651 Cap, Hydro Tank, Metal Tank
03 166141 Filter, Hydro
04 225311 Housing, Hydro Filter
05 203951 Fitting, Filter, 90 Degree
06 226151 Fitting, 90 Degree, Hydro Tank
07 226271 Tee, Pipe, 3/8"
08 226161 Fitting, Straight, Hydro Tank
09 227881 Clamp, Hose, 3/8"
10 226251 Hose, Tank to Pump, 5-1/2"
11 226231 Hose, Tank to Filter, 12"
12 226241 Hose, Filter to Pump, 18"
13 228401 Bolt, 1/4"-20 x 3/4" HCS
14 161900 Washer, Split, 1/4"
15 161910 Washer, Flat, 1/4"
16 227811 Bolt, 5/16"-18 x 1" HCS
17 228001 Washer, Split, 5/16"
18 227961 Washer, Flat, 5/16"
Parts List - Hydro Belt Configuration
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
01 226631 Idler Assembly
02 202061 Pulley, Idler, Deck
03 202071 Pulley, Engine Drive
04 167270 Bolt, Eye, 5/16"-18 x 3-1/2"
05 209211 Belt, Hydro
06 167261 Spring, Mule Drive
07 202081 Pulley, Hydro Drive
