70 DR

®

VERSA-PRO

Z-MOWER

Parts List - Control Arm Assembly

NOTE:

Part numbers listed are available through DR Power Equipment.

Ref# Part#

Description

01 227901 Nut,

Nylock,

1/4"-20

02

228231 Washer, Plastic, 1/4"

03

227551 Handle, Throttle

04

227791 Bolt, 1/4"-20 x 1-1/2" HCS

05

227771 Spacer, 1/4" ID

06

227561 Mount, Throttle Cable

07

228211 Fitting, Pipe, Straight, 1/8"

08 226371 Control

Arm

Assembly

09

208991 Bracket, Control Shield End

10

228111 Bushing, Machine, 1" ID, 18 Gauge

11

199131 Upper Concentric Assembly

12

225251 Bearing, Control Head

13

226111 Block, Concentric Pillow

14

226381 Shield, Control Arm

15 225301 Chain,

69"

16

225241 Bearing, Main Arm Pivot

17

199141 Lower Concentric Assembly

18

158520 Grip, Throttle/Brake

19

241261 Handle, Control, Right

20

158621 Handle, Control, Left

21 200661 Turnbuckle
22

226101 Swivel, Throttle Wire

23

226581 Spacer, Pillow Block

24 226561 Clamp,

Small

25 226571 Clamp,

Large

26

226351 Guard, Chain, Ride Mode, LH

27

226361 Guard, Chain, Walk Mode, RH

28

227891 Clamp, Throttle Cable

29

227871 Screw, Truss, 1/4" x 1/2"

30

228221 Grease Fitting, 1/8"-90° Pipe

31

235141 Lever, Operator Presence

32

241231 Spring, OPC Lever

33

241241 Switch w/Leads and Boot

34

241221 Pin, Spring, 3/16" x 1"

35

225261 Bushing, Bronze, 1" ID

Ref#

Part#

Description

36

225281 Bearing, Needle, 1" ID

37

228121 Bushing, Machine, 1-1/2" ID,18 Ga.

38

225291 Bearing, Needle, 1-1/2" ID

39

226051 Fitting, Grease, Drive, 5/16"

40

225271 Bushing, Bronze, 1-1/2" ID

41

228181 Ring, Snap, 1-1/2"

42

227541 Tube, Lower, Inner

43

227581 Tube, Upper/Lower, Outer

44

227571 Tube, Upper, Inner
