DR Power Z-Mower 19.5 HP Versa-Pro - Manual (Page 68)

64 DR
®
VERSA-PRO
™
Z-MOWER
Parts List - Arm Rest Assembly w/Rear Guards
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 241131 Frame
02
228611 Rear Mower Guard for 22 HP Briggs & Stratton Engine
03 226621 Rear Mower Guard for 19.5 HP Briggs & Stratton Engine
04 241151 Guard, Rear
05 228271 Bolt, 3/8"-18 x 3/4" HCS
06 228291 Bolt, 3/8"-18 x 1" HCS
07 241141 Guard, Debris
08 227801 Bolt, 5/16"-18 x 3/4" HCS
09 227911 Nut, Nylon Lock, 5/16"-18
10 227961 Washer, Flat, 5/16"
11 228241 Nut, Lock, Wiz, 3/8"
12 227601 Latch, Control Arm
13 158430 Housing, Control Arm Latch
14 225191 Tube, Control Rest
15 227511 Spring, Lock Out
16 228301 Bolt, 1/4"-20 x 1-3/4" HCS
17 227921 Nut, Nylock, 3/8"-16
18 227901 Nut, Nylock, 1/4"-20
19 227971 Washer, Flat, 3/8"
20 227861 Bolt, 3/8"-18 x 3" HCS
21 241241 Switch w/Leads and Boot
