Connecting the Battery Wire
We ship all Electric-Starting systems with the negative terminal Battery wire disconnected. This prevents the
Battery from discharging during shipment. Before using your DR VERSA-PRO Z-MOWER, you must
connect the Battery wire.
Attach the Negative Battery wire to the Negative Battery terminal (Figure 3) with the Screw and Nut
provided on the Battery Terminal.
Connect Negative Battery Wire
Figure 3
Battery
