CALL TOLL-FREE 1-800-DR-OWNER 35
LEAF and LAWN VACUUM Tips
Tip: For the most efficient use of the DR LEAF and LAWN VACUUM, use this sequence of steps:
PICKUP STONES, METAL OBJECTS, GLASS, AND STICKS BEFORE VACUUMING.
1. Gather and pile sticks for chipping.
2. Chip the smaller sticks and branches.
3. Remove the Rear Panel and load the larger limbs (Figure 35).
4. Dump the load at the desired location.
5. Mow and vacuum leaves.
Tip: Be careful in corners. Practice in first gear to understand the effects of the Trailer on your ability to turn
sharply. Drive your DR LEAF and LAWN VACUUM into the corner of your property and back out
straight to mow as close to the corner as possible. Avoid going thru ditches.
Tip: We have provided Eyebolts on the sides of the Collector Box so that you can attach accessories or other
tools to transport them around the work site. Items can be attached with ropes or elastic (Bungee)
cords provided by the user.
Tip: The Lawn Deck will tend to scatter some leaves in front and to the right of the Lawn Deck. Keeping the
discharge side toward the remaining leaves will simplify cleanup by avoiding blowing leaves back onto
the areas that you already finished. When you need to vacuum with the discharge side toward the
completed area of the lawn, then overlap the discharge side of the Lawn Deck at least a foot over the
already completed section of the lawn.
Tip: To prevent clogging the Lawn Deck Adapter and Vacuum Hose, mow grass that is dry and not more 2"
at a time. To keep your grass healthy, we recommend cutting less than 1/3 the grass height.
Tip: Run your Lawn Deck with your Tractor at full throttle all the time to maximize the lift from your Lawn
Deck and assist your DR LEAF and LAWN VACUUM system.
Tip: Avoid dragging the Inlet Hose over curbs, stonewalls, or piles of cut branches. The Hose is tough, but
can puncture on sharp objects. This could also crack the Mower Deck Adapter.
