14 2034CL-Q, 300 Clip Instant Access System, Quantel Protocol
Reference . . .
16. SETUP MENU
Press [MENU]. The MENU indicator will turn on.
Turn the Wheel to select item to change.
Press [MENU] OR use the Softkeys to change the desired mode for that option.
Turn the Wheel at anytime to select another item.
Press [ESC] at anytime to exit SETUP MENU. The MENU indicator will turn off.
MENU MODES (Turning Wheel Clockwise)
RECORD Press Softkey to select the desired record mode:
Assemble, Insert, Lockout or Crash (Full).
WIND
MODE
Press Softkey to select:
HOLD (fast wind is maintained only while key is depressed).
OR
LATCH (fast wind is initiated and maintained with momentary key press).
Select fast wind speed (03.9X, etc.) by pressing Softkey.
SLOMO ST300 display shows
(Non T-Bar version):
ST300 display shows
(T-Bar version):
Press Softkey [TBAR] (or [WHEEL]) to toggle between T-BAR and WHEEL.
NOTE - The T-BAR has a fixed speed range of 0Æ+200 with a detent at +100% play speed.
For Wheel only:
Press Softkey [SPDRANGE] to select SLOMO speed ranges:
Press Softkey to select 0 Æ +200 OR –100 Æ +200.
Press Softkey [BACK] to return to SLOMO MENU.
Press [ESC] to exit SETUP MENU
OR turn the Wheel to select another item.
(Continued on next page.)
SLOMO with: WHEEL
SpdRange Preset
SLOMO with: TBAR
Wheel SpdRange Preset
