Maintenance & Troubleshooting 4-30
4.26 Replacement Parts List – Data Distributor Displays
Part Description Daktronics Part No.
8x16 Lens Reflector Assembly; Starburst 0A-1176-0061
8x16 Lens Reflector Assembly; SunSpot 0A-1176-0062
Electrical Contact Lubricant & Protector (paste) 8oz jar CH-1021
Column Director Card 0P-1145-0068
Data Distributor Output Card 0P-1145-0078
Data Distributor Receiver Board 0P-1145-0050
Fan, 120 Volt, 1060 CFM w/ Capacitor 0A-1176-0012
Fan Control Expander Card 0P-1176-0010
Fan Controller Card 0P-1176-0003
Fan Filter, 19.62” x 15.62” 0A-1176-0009
Fuse, Power Harness, MDL-7; ¼” x 1 ¼” Slow-Blow F-1031
Lamp, T-3 ¼, Wedge Base DS-1241
Lampbank, 816-10 with Xenon Lamp 0P-1176-0001
Lens; Blue - StadiaView DS-1232
Lens; Green - StadiaView DS-1234
Lens; Red - StadiaView DS-1233
Lens; Starburst White - StadiaView DS-1231
Lens; Monochrome White - StadiaView DS-1235
Line Controller Card 0P-1145-0044
Portable Test Fixture; 1 ½ & 2 ½ Lampbank, 120V 0A-1176-0007
Safety Lanyard 0A-1176-0010
Socket, Mini-Wedge Base X-1209
Transformer (120V), Marquee T-1107
Weather Stripping, Pile HS-1149
Tool Kit – (includes the following items) 0A-1176-0008
Front Access Module Remover Tool 0M-95442
Lamp Voltage Tester 0P-1089-0010
Lamp/Lens Extractor TH-1032
Electrical Contact Cleaner & Lubricant, 1 oz. Jar CH-1019
Electrical Contact Cleaner, Spray Can CH-1015
0.032 Feeler Gauge 0M-69133
Rear Access Tool Module Remover Tool 0M-95441
5-Inch, 20-Position Cable (LC to Module) W-1356
12-Inch, 20-Position Cable (8x4 Module to 8x4 Module) W-1357
18-Inch, 20-Position Cable (8x16 to 8x16 and 8x8 to 8x8) W-1387
3-Foot, Cat-5 Cable (CD to LC and LC to LC) W-1382
10-Foot, Cat-5 Cable (CD to CD) W-1383
