36 Using the FLR3-1500 and FLD3-2000 Handheld Console
Com Port Tests
PoS Status
About
LCD Screen Action
Press ENTER.
Press ENTER to run test.
Watch the screen on the DM-100 for test results
Press the
CLEAR/SET FUNCTION button to go back.
Press the Down Arrow to scroll to a new test.
Press ENTER to run test.
Watch the screen on the DM-100 for test results
Press the
CLEAR/SET FUNCTION button to go back.
Press the Down Arrow to scroll to a new test.
Press ENTER to run test.
Watch the screen on the DM-100 for test results
Press the
CLEAR/SET FUNCTION button to go back.
Press the Down Arrow to scroll to a new test.
Press ENTER to run test.
Watch the screen on the DM-100 for test results
Press the
CLEAR/SET FUNCTION button to go back.
COM PORT TESTS
ENT TO SELECT
SELECT TEST ↓
RS232 COM0
SELECT TEST ↓ ↑
RS232 COM0 → COM1
SELECT TEST ↓ ↑
RS232 COM1
SELECT TEST ↑
CURRENT LOOP
LCD Screen Action
Press ENTER.
Watch the screen on the DM-100 for test results
Press the
CLEAR/SET FUNCTION button to go back.
DIAGNOSTICS ↓ ↑
POS STATUS
DIAGNOSTICS
BS232 00
LCD Screen Action
Press ENTER to view the firmware version currently loaded on the
DM-100 and the function DM-100 currently in use (gas price, rate,
ERTD) on the handheld controller.
Press ENTER to exit About.
ABOUT
ENT TO VIEW
ABOUT → FIRMWARE
DD-XXXXXXX X.X
ABOUT → FUNCTION
GAS PRICE
