Using the FLR3-1500 and FLD3-2000 Handheld Console 35
Test Patterns
Communication Diagnostics
LCD Screen Action
Press ENTER.
Press the Up and Down Arrow keys to move to another test pattern
option.
Press ENTER to start segment march test pattern.
Press CLEAR/SET FUNCTION to leave Test Pattern option.
Press ENTER to show line number, address, dimming mode, and
temperature on displays.
Press
CLEAR/SET FUNCTION to leave this test pattern option.
Press ENTER to cycle numbers on the display (1.11 9/10, 2.22 9/10,
3.33 9/10, etc).
Press
CLEAR/SET FUNCTION to leave this test pattern option.
The DM-100 moves to the next Diagnostic option automatically.
TEST PATTERNS
ENT TO START
ENTER CYCLE BITS
CLEAR TO EXIT
ENTER DIAGNOSTIC
CLEAR TO EXIT
ENTER CYCLE NUMS
CLEAR TO EXIT
LCD Screen Action
Press ENTER.
Press ENTER.
Enter 1 for Yes to use defaults:
Baud Rate 9600
Stop Bits 1
Enter 2 for No to use specific Baud Rate and Stop Bit values.
Use the
Up Arrow to change the Baud Rate that your PoS system
uses. Typically it is 9,600, but your system may be different. Consult
your PoS system manual for specifics.
Use the Up Arrow to select a Stop Bit Value of 1 or 2.
Press ENTER when finished.
This mode disables price updating to the displays
Press CLEAR/SET FUNCTION to exit this mode..
COM DIAGNOSTICS
ENT TO SELECT
DIAGNOSTICS ↓↑
POS PORT MONITOR
SELECT BAUD RATE
1200 ↑
USE POS DEFAULTS?
1- YES 2-NO
SELECT STOP BITS
1 ↑
INCOMING DATA...
