CDM-550T Satellite Modem Revision 3
KST-2000A FSK Remote Operation MN/CDM550T.IOM
(ODU:) ENABLE
Æ CONFIG Æ TRANSMITTER Æ HPA Æ STATE
SELECT KST HPA STATE:
ON OFF (PRESS ENTER)
Note: If the HPA power is OFF, it cannot report errors, answer messages, provide serial
numbers, etc.
(ODU:) ENABLE
Æ CONFIG Æ TRANSMITTER Æ HPA ÆFAULT- LOGIC
SELECT HPA FAULT LOGIC:
SUMMARY NO-SUMM (ENTER)
Select from the options shown using the [
←] [→] keys, then press .
D.2.2.1.1.2 (ODU:) ENABLE
ÆCONFIG Æ RECEIVER
ODU RX: FREQUENCY ATTEN
LNA (PRESS ENTER)
Select which ODU Receiver parameter is to be modified using the [
←] [→] keys, then
press .
(ODU:) ENABLE
ÆCONFIG Æ RECEIVER Æ FREQUENCY
EDIT ODU RX FREQUENCY:
10950.0 MHz (PRESS ENT)
Edit the receive frequency by selecting the digit to be edited using the [
←] [→] keys.
The value of the digit is then changed using the [
↑] [↓] keys. The user may then press
.
D–5
