Comtech EF Data CDM-550T - Manual (Page 137)

CDM-550T Satellite Modem Revision 3
Remote Control MN/CDM550T.IOM
15–21
Parameter
Type
Command
(Instruction
Code and
qualifier)
Arguments for
Command or
Response to
Query
Description of arguments
(note that all arguments are ASCII numeric codes, that is,
ASCII codes between 48 and 57)
Response to Command
(target to controller)
Query
(Instruction
Code and
qualifier)
Response to
query
(target to
controller)
Redundancy
State N/A 1 byte, value of
0 or 1 Query only.
Returns the redundancy state of the unit, where:
0 = Off Line (forced into standby by 1:N or 1:1 Switch) 1= On
Line (normal). All other codes invalid. Example: RED=1 (On
Line) N/A RED? RED=x (see
description for
details of
arguments)
Equipment
ID N/A 6 bytes,
numerical
Query only.
Unit returns the equipment identification, and the options fitted,
in the form aaaabc,
where:aaaa defines the Modem model number.
2550 is CDM-550T, no Reed-Solomon or Turbo
3550 is CDM-550T with Reed-Solomon Codec
4550 is CDM-550T with Turbo Codec fitted (Rate 3/4 QPSK
only - S/W Version less than 1.15)
5550 is CDM-550T with Turbo Codec fitted (Rate 3/4 QPSK,
plus Rate 21/44 and Rate 5/16 BPSK)
6550 is CiM-550T, no Turbo
7550 is CiM-550T, with Turbo
where: b defines the IF band, with 1 = 70MHz, 2 = 140MHz
c defines RX only, with 1 = RX/TX, 2 = RX only.
Example: EID=455011 (CDM-550T, Rate 3/4 Turbo Codec, 70
MHz band, RX/TX)
N/A EID? EID=aaaabc
(see description
for details of
arguments)
Software Revision N/A 4 bytes,
numerical Query only.
Unit returns the value of internal software revision installed in
the unit, in the form x.xx
Example: SWR=1.03 (Ver 1.03) N/A SWR? SWR=x.xx (see
description for
details of
arguments)
