CDM-550T Satellite Modem Revision 3
KST-2000A FSK Remote Operation MN/CDM550T.IOM
The display has two lines each of 24 characters. On most menu screens, a flashing solid block
cursor blinks once per second to indicate the currently selected item, digit, or field. Where this
solid block cursor would obscure the item being edited (for example, a numeric field) the cursor
will automatically change to an underline cursor.
D.2 Menu Trees
Refer to Figure 6-3 in Chapter 6. FRONT PANEL OPERATION for the hierarchal menu
structure of the CDM-550T.
D.2.1 SELECT: (Top level) Menu
SELECT: CONFIG TEST INFO
MONIT STORE/LD UTIL ODU
The user is presented with the following choices:
CONFIG (Configuration) This menu branch permits the user to fully configure the modem.
TEST This menu branch permits the user invoke one of several modem test modes
(loopbacks, for example).
INFO (Information) This menu branch permits the user to view information on the modem,
without having to go into configuration screens.
MONIT (Monitor) This menu branch permits the user to monitor the alarm status of the
modem, to view the log of stored events, and to display the Receive Parameters
screen.
STORE/LD (Store/Load) This menu branch permits the user to store and to retrieve up to 10
different modem configurations.
UTIL (Utility) This menu branch permits the user to perform miscellaneous modem
functions, such as setting the Real-time clock, adjusting the display brightness, etc.
ODU (Outdoor Unit) This permits the user to monitor and control a Comtech EF Data
KST-2000A Transceiver, if connected.
Detailed information about the first six submenus is provided in Chapter 6. FRONT
PANEL OPERATION. The ODU submenu is fully outlined in the sections that follow.
D–2
