3.3.4 Supervisor Objects
Class Code 30 HEX
This object models the interface, functions and behaviour associated with the management of application objects for
devices within the “Hierarchy of Semiconductor Equipment Devices”
SUPERVISOR OBJECT’S INSTANCE ATTRIBUTES (Instance = 1)
DEVICE
SUPERVISOR
OBJECT
ATTRI‐
BUTE
ATTRIBUTE NAME
SERVICE
CODE
DATA TYPE FLOW‐BUS Comment
0x30 0x01 Number of Attributes 0x0E USINT 20
0x30 0x02 Attribute List 0x0E Array of USINT
0x30 0x03 Manufacturer’s Device Type 0x0E SHORT‐STRING 113,1; Char[6] “MFM" or "MFC”
0x30 0x04 SEMI Standard Revision 0x0E SHORT‐STRING “E54‐0997”
0x30 0x05 Manufacturer’s Name 0x0E SHORT‐STRING “Bronkhorst High‐Tech”
0x30 0x06 Manufacturer’s Model # 0x0E SHORT‐STRING 113,2; Char[14]
0x30 0x07 Digital MFC Software Revision
Level
0x0E SHORT‐STRING 113,5; Char[5] “V6.XX”
0x30 0x08 DeviceNet Hardware Revision
Level
0x0E SHORT‐STRING 113,7; Char[1] “C”
0x30 0x09 Manufacturer’s Serial Number 0x0E SHORT‐STRING 113,3; Char[20] Unique serial nr. for BHT
instruments
0x30 0x0A Device Configuration 0x0E SHORT STRING 113,4; Char[16] Manufacturer configuration
0x30 0x0B Device Status 0x0E USINT
0x30 0x0C Exception Status 0x0E BYTE
0x30 0x0D Exception Detail Alarm 0x0E STRUCT
0x30 0x0E Exception Detail Warning 0x0E STRUCT
0x30 0x0F Alarm Enable 0x0E, 0x10 BOOL 0‐1
0x30 0x10 Warning Enable 0x0E, 0x10 BOOL 0‐1
0x30 0x13 Last Maintenance Date 0x0E DATE 113,11; Char[8] Service date
0x30 0x17 Running Hours 0x0E UDINT 118,2 0‐65535
0x30 0x64 Init Mode 0x0E, 0x10 USINT 0,10 0,64,73,82
0x30 0x65 Monitor 0x0E, 0x10 USINT 115,2 0: measure=setpoint
0x30 0x66 Default_Inp_IO_Assembly_Inst 0x0E, 0x10 USINT
0x30 0x67 Default_Outp_IO_Assembly_Inst 0x0E, 0x10 USINT
Device status
Attribute value State
0 Undefined
1 Self testing
2 Idle
3 Self test Exception
4 Executing
5 Abort
6 Critical fault
7‐50 Reserved by CIP
51‐99 Device specific
100‐255 Vendor specific
Exception Status
Bit
Exception status bit map, Bit 7 set to 0
Function
State
0
Device specific definition
Alarm/device‐common
1 Alarm/device‐specific
2 Alarm/manufacturer‐specific
3 reserved – set to 0
4 Warning/device‐common
5 Warning/device‐specific
6 Warning/manufacturer‐specific
7 0=basic method 1= Expanded Method
