High Availability
Dlink DRO-210i User Guide 30
Select Interface → → → → WAN1 and choose IP Setting Mode as Static or Dynamic. Click on
Detect Link Status to configure the Ethernet WAN Link Detection as explained
below.
Ethernet WAN Link Detection
Interface The WAN interface on which link detection is to be performed.
Link Detection Select to enable Link Detection on this Interface.
Mode Select protocol (ARP or ICMP) used to detect reachability of the default
gateway IP address. If the default gateway is reachable, then the Protocol
Status of the Interface will be UP, otherwise it will be DOWN.
No of Retries Enter the number of attempts to reach the default gateway, before
confirming the status (UP/DOWN) of the link.
Delay between
Retries Enter the time in seconds between retry attempts.
After entering all the information press the Apply button. The Ethernet WAN Status
Table will display the list of interfaces on which Link Detection is enabled and their
status.
Web UI
