Artesyn MVME8100 RTM (VXS1-RTM1) Installation and Use (April 2015) - Manual (Page 46)

Controls, LEDs, and Connectors
VXS1-RTM1 Installation and Use (6806800P46C) 46
3 PMC_IO<3> 35 PMC_IO<35>
4 PMC_IO<4> 36 PMC_IO<36>
5 PMC_IO<5> 37 PMC_IO<37>
6 PMC_IO<6> 38 PMC_IO<38>
7 PMC_IO<7> 39 PMC_IO<39>
8 PMC_IO<8> 40 PMC_IO<40>
9 PMC_IO<9> 41 PMC_IO<41>
10 PMC_IO<10> 42 PMC_IO<42>
11 PMC_IO<11> 43 PMC_IO<43>
12 PMC_IO<12> 44 PMC_IO<44>
13 PMC_IO<13> 45 PMC_IO<45>
14 PMC_IO<14> 46 PMC_IO<46>
15 PMC_IO<15> 47 PMC_IO<47>
16 PMC_IO<16> 48 PMC_IO<48>
17 PMC_IO<17> 49 PMC_IO<49>
18 PMC_IO<18> 50 PMC_IO<50>
19 PMC_IO<19> 51 PMC_IO<51>
20 PMC_IO<20> 52 PMC_IO<52>
21 PMC_IO<21> 53 PMC_IO<53>
22 PMC_IO<22> 54 PMC_IO<54>
23 PMC_IO<23> 55 PMC_IO<55>
24 PMC_IO<24> 56 PMC_IO<56>
25 PMC_IO<25> 57 PMC_IO<57>
26 PMC_IO<26> 58 PMC_IO<58>
27 PMC_IO<27> 59 PMC_IO<59>
28 PMC_IO<28> 60 PMC_IO<60>
29 PMC_IO<29> 61 PMC_IO<61>
Table 3-14 PIM Connector (J14) (continued)
Pin Name Signal Name Pin Name Signal Name
