Introduction
VXS1-RTM1 Installation and Use (6806800P46C) 24
1.3 Mechanical Data
Table 1-2 provides details on the board’s mechanical data.
1.4 Ordering Information
When ordering board variants, use the order number given in the following table.
CISPR 22
EN 55022
EN 55024
FCC Class A
VCCI Japan
AS/NZS CISPR 22 EMC requirements (legal) on system level (predefined Artesyn
system)
ETSI EN 300 019 series
Environmental Requirements
Directive 2002/95/EC Directive on the restriction of the use of certain hazardous
substances in electrical and electronic equipment (RoHS)
Table 1-1 Board Standard Compliances (continued)
Standard Description
Table 1-2 Mechanical Data
Characteristic Value
Height 233.44 mm
Depth 80 mm
Width 20.32 mm
Weight 230 g
Model Number Description
VXS1-RTM1 RTM for MVME8100
