Transition Module
MVME7100ET Single Board Computer Installation and Use (6806800K87E) 86
There are two sets of ACT and SPEED LEDs, one set for each Ethernet connector. They are
described in the next table.
5.6 PMC Input/Output Module
If a PMC Input/output Module (PIM) has already been installed on the MVME721ET, or you are
installing a transition module as it has been shipped from the factory, disregard this procedure
and refer to
Transition Module on page 40 .
Procedure
For PIM installation, perform the following steps:
1. Attach an ESD strap to your wrist. Attach the other end of the ESD strap to the
chassis as a ground. The ESD strap must be secured to your wrist and to ground
throughout the procedure.
2. Carefully remove the transition module from its packaging and lay it flat on a stable
surface.
3. Remove the PIM filler from the front panel of the transition module.
4. Slide the face plate (front bezel) of the PIM module into the front panel opening
from behind and place the PIM module on top of the transition module, aligned
with the appropriate two PIM connectors. The two connectors on the underside of
the PIM module should then connect smoothly with the corresponding connectors
on the transition module (J10 and J14).
5. Insert the four short Phillips screws, provided with the PIM, through the holes on
the bottom side of the transition module into the PIM front bezel and rear
standoffs. Tighten the screws.
Table 5-5 Transition Module LEDs
LED Function
ACT Activity or Ethernet or Gigabit Ethernet connector
SPEED 10/100/1000Mb/s of Ethernet connectors
