Chapter 2
MVME7100ET Single Board Computer Installation and Use (6806800K87E) 25
Hardware Preparation and Installation
2.1 Overview
This chapter provides startup and safety instructions related to this product, hardware
preparation instruction that includes default switch settings. System considerations and
installation instructions for the baseboard, PMC, and transition module are also described in
this chapter.
A fully implemented MVME7100ET consists of the baseboard plus:
 Two single-wide or one double-wide PCI Mezzanine Card (PMC) slot for added versatility.
 One transition module for support of the mapped I/O from the MVME7100ET baseboard
to the P2 connector.
 Up to two optional XMCspan cards.
The following table lists the tasks that you are required to do before you can use this board.
Read this entire chapter, including all Caution and Warning notes, before you begin.
Table 2-1 Startup Overview
Task Page
Unpack the hardware. Unpacking and Inspecting the Board on page 26
Configure the hardware by setting
jumpers on the board and RTM. Configuring the Board on page 33 and SEEPROM Address
Switch, S1 on page 83
Install the MVME7216E transition module
in the chassis. Transition Module on page 40
Install PMC module (if required). Installing Accessories on page 39
Install XMCspan module (if required). XMCspan Installation and Use (6806800H03)
Install the MVME7100ET in the chassis. Installing and Removing the Board on page 44
Attach cabling and apply power. Completing the Installation on page 45
Install PIM on transition module (if
required). PMC Input/Output Module on page 86
Ensure that the firmware initializes the
MVME7100 Chapter 6, MOTLoad Firmware
Initialize the board Chapter 6, MOTLoad Firmware
Examine and/or change environmental
parameters. MVME7100ET Single Board Computer Programmer’s
Reference
