Controls, LEDs, and Connectors
COMX-CORE Series Installation and Use (6806800K11F) 55
A86 KBD_RST# B86 VCC_5V_SBY C86 PEG_RX10- D86 PEG_TX10-
A87 KBD_A20GATE B87 VCC_5V_SBY C87 GND D87 GND
A88 PCIE0_CK_REF+ B88 SPI_CS1# C88 PEG_RX11+ D88 PEG_TX11+
A89 PCIE0_CK_REF- B89 VGA_RED C89 PEG_RX11- D89 PEG_TX11-
A90 GND(FIXED) B90 GND(FIXED) C90 GND(FIXED) D90 GND(FIXED)
A91 SPI_CS0# B91 VGA_GRN C91 PEG_RX12+ D91 PEG_TX12+
A92 SPI_MISO B92 VGA_BLU C92 PEG_RX12- D92 PEG_TX12-
A93 GPO0 B93 VGA_HSYNC C93 GND D93 GND
A94 SPI_CLK B94 VGA_VSYNC C94 PEG_RX13+ D94 PEG_TX13+
A95 SPI_MOSI B95 VGA_I2C_CK C95 PEG_RX13- D95 PEG_TX13-
A96 GND B96 VGA_I2C_DAT C96 GND D96 GND
A97 VCC_12V B97 BIOS_DIS1# C97 RSVD D97 PEG_ENABLE#
A98 VCC_12V B98 SER_TX15/ No
on COMX-CORE
Series module C98 PEG_RX14+ D98 PEG_TX14+
A99 VCC_12V B99 SER_RX15/ No
on COMX-CORE
Series module C99 PEG_RX14- D99 PEG_TX14-
A100 GND(FIXED) B100 GND(FIXED) C100 GND(FIXED) D100 GND(FIXED)
A101 VCC_12V B101 VCC_12V C101 PEG_RX15+ D101 PEG_TX15+
A102 VCC_12V B102 VCC_12V C102 PEG_RX15- D102 PEG_TX15-
A103 VCC_12V B103 VCC_12V C103 GND D103 GND
A104 VCC_12V B104 VCC_12V C104 VCC_12V D104 VCC_12V
A105 VCC_12V B105 VCC_12V C105 VCC_12V D105 VCC_12V
A106 VCC_12V B106 VCC_12V C106 VCC_12V D106 VCC_12V
A107 VCC_12V B107 VCC_12V C107 VCC_12V D107 VCC_12V
A108 VCC_12V B108 VCC_12V C108 VCC_12V D108 VCC_12V
A109 VCC_12V B109 VCC_12V C109 VCC_12V D109 VCC_12V
Table 3-1 COM Express Connector Pin Definition (continued)
Row A Row B Row C Row D
