PROFIBUS DP Slave Communication Module DVPPF02-H2

DVP-PLC Application Manual

1 Introduction

1. To ensure correct installation and operation of DVPPF02-H2, please read this chapter carefully before

using your DVPPF02-H2.

2. This chapter provides only introductory information on DVPPF02-H2. Details of PROFIBUS DP protocol

are not included in this sheet. For more information on PROFIBUS DP protocol, please refer to relevant

references or literatures.

3. DVPPF02-H2 is a PROFIBUS DP slave communication module, connecting DVP-EH2 series PLC to

PROFIBUS DP network.

1.1 Features

1. Supports loop-type data exchange between PROFIBUS DP master and many slaves.

2. The length of I/O data can be freely configured through PROFIBUS DP network configuration tools.

Max. input data length = 100 words (the sum of 4 slots); Max. output data length = 100 words (the

sum of 4 slots).

3. Supports GSD files in PROFIBUS DP network configuration tool.

4. Supports 4 slots in PROFIBUS DP network configuration tool.

5. Auto-detects baud rates; supports Max. 12M bps.

1.2 Specifications

PROFIBUS DP connector

Transmission method

High-speed RS-485

Electrical isolation

500VDC

Interface DB9

connector

Transmission cable

Shielded twisted pair cable

Communication

Message type

DPV0, loop-type data exchange

Equipment ID

0AFE (hex)

GSD file

DELT0AFE.GSD

Module name

DVPPF02-H2

Transmission speed
(Auto-detect)

9.6 kbps、19.2 kbps、93.75 kbps、187.5 kbps、500 kbps、1.5 kbps、3 Mbps、

6 Mbps、12 Mbps

Environment

Noise immunity

ESD (IEC 61131-2, IEC 61000-4-2): 8KV Air Discharge

EFT (IEC 61131-2, IEC 61000-4-4): Power Line: 2KV, Digital I/O: 1KV,

Analog & Communication I/O: 1KV
Damped-Oscillatory Wave: Power Line: 1KV, Digital I/O: 1KV

RS (IEC 61131-2, IEC 61000-4-3): 26MHz ~ 1GHz, 10V/m

Operation/storage

Operation: 0°C ~ 55°C (temperature), 50% ~ 95% (humidity), pollution
degree 2
Storage: -25°C ~ 70°C (temperature), 5% ~ 95% (humidity)

Vibration/shock
immunity

Standard: IEC61131-2, IEC 68-2-6 (TEST Fc)/IEC61131-2 & IEC 68-2-27
(TEST Ea)

Certificates

IEC 61131-2, UL508
