Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.

3

MPPC 2120T/3220T User Manual

Chapter 1: Product Introduction

Specifications

Panel
• MPPC 2120T

LCD size: 21.5”, 16:9
Resolution: full HD, 1920 x 1080
Luminance: 420 cd/m²
Contrast ratio: 3000
LCD color: 16.7M
Viewing angle: 89 (U), 89 (D), 89 (L), 89 (R)
Backlight: LED
Touch screen: 5-line Resistive
Touch light transmission: 80%
Touch interface: USB

• MPPC 3220T

LCD size: 32”, 16:9
Resolution: full HD, 1920 x 1080
Luminance: 400 cd/m²
Contrast ratio: 4000
LCD color: 1073.7M
Viewing angle: 89 (U), 89 (D), 89 (L), 89 (R)
Backlight: LED
Touch screen: SAW (Surface Acoustic Wave)
Touch light transmission: 92%
Touch interface: USB

System
• CPU: Intel

®

Atom™ D525, 1.8Hz

• BIOS: AMI BIOS
• System chipset: Intel

®

ICH8M

• System memory:

1x 204-pin DDR3 SODIMM socket, 1G DDR3 (default),
Supports up to 2GB DDR3 800, Non-ECC and Un-buffered

• SSD: one external locked CF socket by IDE supports Type I/II compact

Flash card

• Hard drive bay: optional 2.5” SATA HDD or SATA DOM
• Watchdog timer: Watchdog timeout can be programmable by

software from 1 second to 255 seconds and from 1 minute to 255
minutes (Tolerance 15% under room temperature 25°C)

• H/W status monitor: Monitors system temperature, and voltage
• Expansion: 2x Mini-PCIe sockets
