D-Link DES-3250TG Standalone Layer 2 Switch
Figure 7- 14. Current Static Router Ports Entries window
To add a static router port configuration, click the pointer icon:
Figure 7- 15. Static Router Ports Settings window
The following fields are displayed:
Parameter Description
VID Displays the name of the VLAN ID the static
router port belongs to.
VLAN Name Displays the name of the VLAN the static
router port belongs to.
Member Ports Each port can be set individually as a router
port by clicking the port’s click-box entry.
Spanning Tree
The Spanning Tree Protocol (STP) operates on two levels: on the switch level, the settings are globally implemented. On the
port level, the settings are implemented on a user-defined Group of ports basis.
46
